Filled PTFE Parts

PTFE has excellent properties and is widely used in industrial sealing, electronics, chemical and other fields.
Cierne Mechanical provides a wide range of PTFE plates, rods, tubes, case and CNC machining products.

Categories: PTFE SERIES, Filled PTFE, CNC PTFE Parts Tags: bronze, carbon fiber, Filled PTFE, glass fiber

Description

Filled PTFE Profile

FILLER ELEMENT	FEATURE	USAGE
GLASS FIBER FILLED PTFE	Strong wear resistance, small friction, excellent electrical performance.	Mechanical and electrical, such as bearings, gaskets, gasket sheet
GLASS FIBER & GRAPHITE FILLED PTFE	Wear resistance, low friction, and creep reduction	Mechanical, such as piston ring, bridge groove, tube bearing pad, not suitable for electrical products
GLASS FIBER & MOS2 FILLED PTFE	Strong wear resistance, small friction, small creep, excellent electrical performance	Mechanical and electrical applications, such as split bearings, valve seats
CARBON FIBER FILLED PTFE	Wear resistance and load resistance	Mechanical applications such as bearings, mechanical seals and bearing pads
GRAPHITE FILLED PTFE	Small friction, good drug resistance, creep smaller	Machinery and pharmaceutical industries, such as bearings, gaskets, gaskets
BRONZE FILLED PTFE	Wear resistance, low friction, high thermal conductivity	Mechanical, such as piston ring, bridge groove, tube bearing pad, not suitable for electrical products

Filled PTFE Technical Data

FILLED ELEMENT OF COMPOSITION PTFE MATERIAL	GRAVITY	HARDNESS	TENSILE STRENGTH	ELONGATION	COMPRESSIBILITY
	ASTM D4894	ASTM D2240	ASTM D4894	ASTM D4894	Internal
	g/cm³	Shore D	MPa	%	%
15%GLASS FIBER FILLED PTFE	2.20-2.24	59-61	23-25	330-360	2.0-2.7
20%GLASS FIBER FILLED PTFE	2.20-2.24	60-65	16-19	290-340	2.0-2.7
25%GLASS FIBER FILLED PTFE	2.22-2.26	60-65	14-17	250-290	2.0-2.7
15%GLASS FIBER + 5%GRAPHTE FILLED PTFE	2.20-2.25	60-65	17-20	260-290	2.0-2.7
15%GLASS FIBER + 5%MOS2 FILLED PTFE	2.24-2.29	60-65	22-24	250-300	2.0-2.7
15%CARBON FIBER FILLED PTFE	2.05-2.15	60-65	18-22	300-340	2.0-2.7
15%GRAPHITE FILLED PTFE	2.15-2.19	55-60	19-23	270-320	2.0-2.7
60%BRONZE FILLED PTFE	3.85-4.00	65-70	15-17	200-250	2.0-2.7
